Attention, please note: NEW, Klon Centaur clone (klone) PCB's or circuit boards have been MFD, are here & NOW shipping to customers.
These are like the very earliest BYOT 2009 version complete with SILK SCREEN LEGEND, DUAL SIDED, PLATED THRU-HOLES, and a green solder mask. The design has been slightly improved and tweaked, including silk screen legend minor corrections, and some more breathing room for some of the resistors, and a better fit for the zener diode.
Many have requested the return of the silk screen legend, and many have liked the double sided, plated thru-hole circuit boards better than the single sided circuit boards.
Thank you for your patronage of BYOT "Build Your Own Tone."
Klon Centaur clone is available for US$240
See the assembled boutique pedals page for complete custom pre-order details. Choose your enclosure color & size & LED color now.
See the custom Klon Centaur clone I built for guitarist supreme Franky Novello of New York glam band ROXX: Ox blood red 1590BB size enclosure with super bright purple LED
I assembled my 1st Klon Centaur clone March 20, 2010. On March 21, 2010 I housed my prototype Klon clone in an unpainted original Hammond 1590B type enclosure with a clear orange super bright LED using a fancy metal LED holder.
This is a fantastic neat overdrive/ booster boutique pedal. Do not hesitate to purchase a Klon Centaur clone, you will be glad you did.
See the assembled Klon Centaur clone type prototype photos here: Klon Centaur clone (Klone) is available for $240
This fantastic looking gloss yellow beauty of a Klon Centaur clone with a SB clear red LED was recently custom ordered and sold to a chap in VA, USA
Klon Centaur clone Circuit Boards are available to distributors only at distributor pricing. Klon Centaur clone type kits are available to everybody!
Purchase a Klon Centaur clone type kit and enjoy the best boutique pedal kit ever!
Please Note: Purchase a Klon Centaur clone type kit and enjoy the best boutique pedal kit ever! Just $65
Parts layout and wiring diagram: Klon Centaur klone parts layout and wiring diagram including electronic component parts net list
Klon Centaur klones built by customers of the Klon Centaur clone type circuit boards. Yes, these circuit boards actually work, and baby they nail it!
Photos courtesy of:
John M of TX, USA
Tony H of CA, USA
Paul V of IL, USA
To see your own Klon Centaur clone boutique pedal kit build here, just contact me, and it will be done. Build Your Own Tone Klon clone circuit board builds only, thank you
Photos of the Klon Centaur clone circuit board are here
Parts layout and wiring diagram: Klon Centaur klone parts layout and wiring diagram. Updated February 8, 2010 with electronic parts net list.
Foreign distributors are very welcome.
Telephone: 604-783-8439
E-mail: starbreaker@netzero.net
Follow me on http://www.twitter.com/superhardon
I have my own space on http://www.myspace.com/buildyourowntone
I have a face on http://www.facebook.com/buildyourowntone
*****Please note*****: I recently received a negative feedback from a disgruntled ebay customer who clearly does not know the difference between the "cathode" and "anode" end of a diode, and consequently ruined his Klon clone type circuit board, and is trying to blame the design of the circuit board for his failure to understand the markings on simple diodes. Intelligent informed minds will see beyond this ruse!!!
Remember basic electronics theory? Banded or striped end of a diode is the (+) Cathode side, and the other side is (-) Anode. School is out!
Klon Centaur Professional Overdrive Clone Type Electronics Kit. Yes folks, a Klon clone type KIT!
The debut of the most highly anticipated boutique pedal kit ever! This is it folks, the wait is finally over, for the Klon Centaur clone type boutique pedal kit.
The original Klon Centaur Professional Overdrive/ Booster (aka: Treble Booster) is just fantastic!
Now, here is your chance to actually build your own famous Klon Centaur clone type boutique pedal kit of this highly desirable, and now very rare Klon Centaur guitar effects pedal.
For a preview, you can see photos (many more to be posted later) here:
http://www.buildyourowntone.com/boutiquepedalkits.html
Please Note: I have listed carefully what is included and what is NOT included with the Klon clone electronic parts kits. Just so you know exactly what you are purchasing (NO misunderstandings).
Please Note: The kits include all of the electronic component parts necessary to populate the circuit board (included), (with the exception of the germ diodes). Sockets are included for the 3 IC chips (2 * TL072 IC's, 1 charge pump IC), which are included.
All of our kits do NOT include the pedal hardware, enclosure and items listed below. The necessary hardware, powder coated enclosure and germ diodes can be purchased from Pedal Parts Plus in Evans, LA and Small Bear Electronics in Brooklyn, NY.
See below:
1) enclosure $8
2) stompswitch $4-$8
3) potentiometers $4
4) jacks (in/out) $2.40
5) DC jack $1.20
6) battery clip $1.50?
7) knobs $2.40
8) LED/ driver resistor (value determined by LED used) chrome metal bezel holder $4
9) germ diodes $1.50
10) stand offs $2?
11) rubber feet $2?
12) wire
13) solder
14) patience
15) goop or epoxy (seriously!)
With the exception of the germ diodes, the hardware prices certainly add to the cost of any boutique guitar effects pedal. The extra cost can be anywhere between $33-$37.
If these hardware parts were included in the kit, the cost would have to be added to the price of the kit.
I feel it is much easier for the customer to purchase these items from the 2 USA based vendors which I have already mentioned, as they are top notch.
From a business perspective, this is a win-win situation for both the consumer and the USA based pedal parts vendors.
You choose the size and color of your enclosure.
You choose the type of germ diodes to use in the Klon Centaur clone.
You choose the IC chips to use (TL072 IC's and sockets are included).
You choose the type of DPDT stompswitch to use, or just use a 3PDT.
You are in control. It is your tone. Ain't nothin cept TONE.
The Klon clone type kits are very easy to assemble (just like paint by numbers).
There are (34) individual small ziploc bags which contain all of the included electronic component parts. This aids in the identification of all of the parts and very easy parts placement.
"Are the caps the Panasonics spec'd on the parts list?"
Yes, the caps are the Panasonic brownie type, which are the metal poly film type. The electrolytic caps are also Panasonic (Matsushita corp).
Please note: I substituted a 12.1K value metal film resistor for the 12K, but it is still within the -+1% range tolerance.
Only the highest quality electronic parts components have been used for the Klon Centaur clone type boutique pedal kit.
All the electronic component parts values are individually separated with small ziploc bags (34) in total.
The kit build is much easier with this arrangement.
Any questions? My e-mail address: starbreaker@netzero.net
Good luck with the build, and I hope you enjoy this unique guitar effects pedal when fully assembled and completed.
Build your own TONE!
The Klon Centaur type clone circuit board is designed with the highest quality in mind. It is a double sided, plated thru hole, solder masked, and silk screen legend circuit board.
This boutique pedal kit is for the novice or experienced boutique pedal guitar effects builder or hobbyist. It is a fairly simple build. The circuit board can fit into a Hammond 1590B or a 1590BB type enclosure. NSC is a very good brand that is lower cost for the same type aluminum enclosures.
You can view and download the (2) parts layout and wiring diagram graphics here:
http://www.buildyourowntone.com/klontypeclonepartslayoutandwiringdiagram.html
Download the (2) graphic images and think about building the most highly sought after, and desirable boutique pedal ever! Really, is there any other? ;-)
Update: I have posted the electronics parts net list on my website, so it will be easier to evaluate, and for the Ebay purchasers to download immediately. Easier for us all. Have fun and enjoy :-)
Shipping and Handling is via 1st Class Postage from British Columbia, Canada.
Good luck building your new boutique pedal kit, guitar effects pedal. Enjoy :-)
Is guitar boutique pedal cloning moral, ethical, legal? Read this thread from Harmony-Central:
http://acapella.harmony-central.com/forums/showthread.php?t=1834305
